Gehl R105 Troubleshooting

The Gehl R105 skid steer loader is powered by 100.2 cu.in (1.6L) Yanmar 3TNV88C three-cylinder direct injection liquid-cooled diesel engine with a rated power of 34.7 hp (25.5 kW) at 2800 rpm. The Gehl R105 is equipped with a single-speed hydrostatic transmission, radial-lift loader boom, 80H roller chains, and 27-8.5x15 tires. The hydraulic system has a pump with fluid flow rate of 14.5 gpm (55 lpm). The hydraulic pressure is 2750 psi (190 bar). The skid steer loader has a rated operating capacity of 1050 lbs (475 kg) and tipping load of 2100 lbs (950 kg). The lift height is 107.5 inches (2730 mm) to hinge pin, and dump height is 82 inches (2085 mm).

Engine Troubleshooting

Engine hard to start or doesn't start
Air in the fuel system - Air bleeding.
Fuel filter element clogging - Change the filter element.
Defective or clogged injection nozzle - Inspect nozzles and replace if necessary.
Dirt or water in fuel system - Drain water or flush dirt from the system.
Valve out of adjustment - Adjustment procedure required.
Fuel injection pump failure - Change or repair the pump.

Engine starts and then shuts off
Air filter is plugged - Clean or change.
Fuel filter plugged - Install new filter element.
Fuel injection pump has loose connections - Tighten the connections.
Fuel injectors are dirty or defective - Replace or clean fuel injectors.
Fuel injection pump is not working correctly - Install a new pump or rebuild.

Engine stalls while running
Low coolant temperature - Warm up the engine.
Fuel filter element is clogged - Change the filter element.
Air in fuel tank - Bleed fuel tank.
Dirty or faulty injection nozzles - Test injection nozzles and change if necessary.
Incorrect adjustment of fuel injection pump timing - Use the correct fuel injection pump timing adjustment.

Engine stalls while idling
Low idle speed adjustment is incorrect - Adjustment required.
Fuel injection pump is broken - Rebuild or replace pump.
Damaged or clogged injectors - Replace or clean fuel injectors.
Valve out of adjustment - Adjust valve clearance.

Engine power is too low
Air filter is clogged - Replace or clean air filter element.
Fuel injection nozzles fault - Check and replace nozzles if required.
Fuel injection pressure is incorrect - Check the fuel injection pressure and adjust if necessary.
Valve clearance is wrong - Adjust to proper valve clearance.
Low idle speed setting is incorrect - Correct the settings.
Clogged fuel lines or hoses - Clean fuel hoses and lines.
Cylinder head gasket defective - Replace the gasket as required.
Worn or broken piston rings - Replace piston rings.

Engine is overheated
Engine coolant is insufficient - Refill to the correct level and inspect system for leaks.
Engine oil insufficient - Check and refill engine oil.
Dirty radiator fins or defective radiator cap - Replace cap or clean radiator.
Loose or defective fan belt - Belt replacement is recommended.
Engine overload - Reduce engine load.

Low oil pressure
Not enough oil in the engine - Fill crankcase to proper oil level.
Oil filter is clogged - Replace or clean engine oil filter element.
Improper type of engine oil - Fill up with the correct oil viscosity.
Excessive crankshaft bearing oil clearance - Replace bearings.
Oil pump failure - Repair or replace.

Abnormal engine knocking or noise
Engine oil insufficient - Check and refill engine oil.
Engine is not warmed up to required temperature - Warm up the engine.
Incorrect adjustment of fuel injection pump timing - Set up as recommended.
Too low idle RPM - Adjust low idling as recommended.
Fuel injectors are dirty or defective - Clean or replace fuel injectors.
Connecting rod is defective or not aligned - Replace or align connecting rod.
Worn or broken pistons - Replace the pistons.

Drive System Troubleshooting

Machine is not moving forward or backward
Insufficient hydraulic oil - Need to add oil.
Drive chain is damaged - Check drive chain and change faulty parts.
Worn input drive shaft - Service or change drive shaft.
Relief valve is defective - Service or change relief valve.
Dirty suction line or hydraulic filter - Service suction line or replace hydraulic filter.
Foot or hand controls are defective - Inspect and repair if necessary.
Defective drive pump or motor - Inspect and change as required.

Loss of power
Hydraulic oil filter is clogged - Check, clean, or replace as required.
Opened or defective relief valve - Replace or close relief valve.
Transmission parts are damaged or faulty - Check and change faulty components.
Input drive shaft is defective - Service or change faulty drive shaft.
There is air in the hydraulic system - Air bleeding is required.

Drive system keeps overheating
Low hydraulic oil level - Need to add oil.
Hydraulic fluid filter is plugged - Check, clean, or replace as required.
Relief valve is defective - Repair or change.
Hydraulic motor or drive pump failure - Check and repair if required.
Clogged hydraulic oil cooler - Cooling fins should be cleaned.
Overloaded drive system - Load needs to be reduced.

Drive system makes excessive noise
Improper oil viscosity - Use proper oil viscosity.
There is air in the hydraulic system - Bleed hydraulic system.
Worn hydraulic motor or drive pump - Inspect and replace as necessary.
Mechanical parts of drive system are worn or damaged - Check the components for defect or damage and change if necessary.

Hydraulics Troubleshooting

Hydraulic system has overheating
Hydraulic pressure is incorrect - Adjust pressure as required.
Main relief valve malfunction or improper adjustment - Replace or set up the relief valve.
Hydraulic oil is contaminated - The oil must be changed.
Hydraulic fluid level is insufficient - Add fluid to the hydraulic system.
Hydraulic pump is faulty - Repair or install new hydraulic pump.

Boom won't lower or raise
Lift controls malfunction - Repair or replace.
Hydraulic pump failure - Repair or install new hydraulic pump.
Hydraulic control valve malfunction - Repair or change hydraulic valve.
Defective hydraulic cylinder - Repair or install a new lift cylinder.
Hydraulic fluid is insufficient - Fill the system to proper hydraulic fluid level.

Bucket can't tilt
Bucket tilt controls are defective - Repair or change.
Hydraulic pump is broken - Replace or repair pump if necessary.
Hydraulic control valve malfunction - Repair or change hydraulic valve.
Bucket cylinder malfunction - Replace or repair cylinder.
Low hydraulic oil level - Fill the system to proper hydraulic oil level.

Bucket or lift arm runs slowly
Hydraulic pump is faulty - Check hydraulic pump flow and replace pump if necessary.
Hydraulic cylinder leaking - Change cylinder piston seals.
Insufficient hydraulic fluid - Fill the system to proper hydraulic fluid level.
Hydraulic control valve is not set properly or defective - Repair or adjust properly.
Hydraulic system loosing pressure - Set pressure correctly.

Lift arm or bucket jerks when working
Hydraulic system is leaking air - Bleed air from hydraulic system.
Plugged hydraulic oil filter - Service or change the hydraulic filter.
Hydraulic fluid is dirty - Hydraulic fluid change required.
Scratched cylinder rod or tube - Change failed component.

Hydraulic pump is noisy
Hydraulic leaks or lack of oil - Top up hydraulic oil or remedy leakage in system.
Clogged hydraulic filter - Service or change hydraulic filter.
Plugged suction line - Suction line needs to be cleaned.
Air trapped in hydraulic pump - Need to bleed air.
Pump components are faulty - Rebuild or change hydraulic pump.

Electrical Troubleshooting

Battery cannot be charged
Wiring connections are corroded or loose - Tighten or clean connections.
Defective battery terminal clamps - Terminal clamps should be changed.
Battery failing - Change the battery.
Loose or worn belt - Belt needs to be adjusted or changed.

Starter turns slowly
Low battery power - Low battery charging, charge as required.
Battery runs out quickly - Service charging system or change battery.
Faulty battery terminals or disconnected cables - Connect cables correctly or replace terminals.

Starter is not cranking
Battery is discharged or defective - Battery needs to be recharged or replaced.
Disconnected or incorrectly connected wires - Inspect battery wires and connect correctly.
Battery power is low - Battery needs to be recharged.
Defective starter motor - Starter should be replaced.
